分支模式#

¥Branch patterns

n8n 实例和 Git 分支之间的关系是灵活的。你可以根据需要创建不同的设置。

¥The relationship between n8n instances and Git branches is flexible. You can create different setups depending on your needs.

Recommendation: don't push and pull to the same n8n instance

You can push work from an instance to a branch, and pull to the same instance. n8n doesn't recommend this. To reduce the risk of merge conflicts and overwriting work, try to create a process where work goes in one direction: either to Git, or from Git, but not both.

多个实例,多个分支#

¥Multiple instances, multiple branches

此模式涉及多个 n8n 实例,每个实例都链接到其自己的分支。

¥This pattern involves having multiple n8n instances, each one linked to its own branch.

你可以将此模式用于环境。例如,创建两个 n8n 实例,分别用于开发和生产环境。将它们链接到各自的分支。将工作从开发实例推送到其分支,然后发起拉取请求将工作移动到生产分支,最后拉取到生产实例。

¥You can use this pattern for environments. For example, create two n8n instances, development and production. Link them to their own branches. Push work from your development instance to its branch, do a pull request to move work to the production branch, then pull to the production instance.

The advantages of this pattern are:

  • An added safety layer to prevent changes getting into your production environment by mistake. You have to do a pull request in GitHub to copy work between environments.
  • It supports more than two instances.

The disadvantage is more manual steps to copy work between environments.

Diagram

多个实例,一个分支#

¥Multiple instances, one branch

如果你希望在所有地方使用相同的工作流、标签和变量,但要在不同的 n8n 实例中使用它们,请使用此模式。

¥Use this pattern if you want the same workflows, tags, and variables everywhere, but want to use them in different n8n instances.

你可以将此模式用于环境。例如,创建两个 n8n 实例,分别用于开发和生产环境。将它们链接到同一个分支。将工作从开发分支推送到生产分支,然后拉取到生产分支。

¥You can use this pattern for environments. For example, create two n8n instances, development and production. Link them both to the same branch. Push work from development, and pull it into production.

此模式在测试新版本的 n8n 时也很有用:你可以使用新版本创建一个新的 n8n 实例,将其连接到 Git 分支并进行测试,同时你的生产实例仍保留在旧版本上,直到你确信升级安全为止。

¥This pattern is also useful when testing a new version of n8n: you can create a new n8n instance with the new version, connect it to the Git branch and test it, while your production instance remains on the older version until you're confident it's safe to upgrade.

The advantage of this pattern is that work is instantly available to other environments when you push from one instance.

The disadvantages are:

  • If you push by mistake, there is a risk the work will make it into your production instance. If you use a GitHub Action to automate pulls to production, you must either use the multi-instance, multi-branch pattern, or be careful to never push work that you don't want in production.
  • Pushing and pulling to the same instance can cause data loss as changes are overridden when performing these actions. You should set up processes to ensure content flows in one direction.

Diagram

One 实例,多个分支#

¥One instance, multiple branches

实例所有者可以更改连接到实例的 Git 分支。在这种情况下,完整的设置很可能是 多个实例,多个分支 模式,但其中一个实例会在分支之间切换。

¥The instance owner can change which Git branch connects to the instance. The full setup in this case is likely to be a Multiple instances, multiple branches pattern, but with one instance switching between branches.

这对于审核工作非常有用。例如,不同的用户可以在各自的实例上工作,并将代码推送到各自的分支。审阅者可以在审阅实例中工作,并在不同分支之间切换以加载不同用户的工作。

¥This is useful to review work. For example, different users could work on their own instance and push to their own branch. The reviewer could work in a review instance, and switch between branches to load work from different users.

No cleanup

n8n 在切换分支时不会清理实例的现有内容。按此模式切换分支,会将每个分支中的所有工作流都添加到你的实例中。

¥n8n doesn't clean up the existing contents of an instance when changing branches. Switching branches in this pattern results in all the workflows from each branch being in your instance.

Diagram

一个实例,一个分支#

¥One instance, one branch

这是最简单的模式。

¥This is the simplest pattern.

Diagram
